Forklift man cages safely elevating personnel in the workplace.

This work platform complies with the applicable requirements of NZS/ANSIJITSDF B56.1:2005 ( Safety Standard for Low Lift and High Lift Trucks). The platform incorporates two fall restraint anchorages rated at I 5kN each and the man cage is rated for a maximum load of 250kg (being a maximum of two persons and tools/equipment).

Forklifts used to lift the platform must be rated at least twice the total load of the platform, i.e. 800kg at 585mm ahead of forks.

Media

Features

MECHANICAL FEATURES

  • Delivery: Flat-packed
  • Finish: Zinc-plated

  • Full length fork pockets for forklift
  • Inwards-opening, self-closing cage door
  • Mesh safety screen
  • Retaining attachment pins
  • Designed to carry 2 persons (250kg max)

Models

CODE AFZ-CIT-001
Capacity (kg) 250
Length (mm) 1084
Width (mm) 1154
Height (mm) 2002
Fork Pocket Size (mm) 160 x 60
Weight (kg) 120
