Manual Lifter GUIL
Front loading Lifting Equipment
Model Number


Working Height - Forks Up (mm)


Working Height - Forks Down (mm)


Height Stowed (mm)


Loading Height (mm)


Net Weight (kg)


Folded Dimensions (mm)

810 x 650 x 1680

Profile Dimension - Width (mm)


Mast Profiles (#)


Capacity (kg)



Enquire For Price

Add to Quote
Specification PDF

The compact lifter, with a stowed height of just 1.68m allows it to be transported in small vehicles. Due to their high load capacities, wide variety of possible applications, compact and maneuverable design and their simple use, the Material Lifts are the perfect machine for any type of manual work.

The lifter is equipped with aluminum high-strength mast profiles which are raised with a pulley system (galvanised steel wire rope with a steel core). It has two folding and adjustable stabilizer legs that allow greater stability of the load and perfect positioning of the lifter. The stabilizers come with two swivel castors. The base is specially designed so that the legs can be inserted both at the front and the back of the tower, giving the option to use it flush to the wall or workspace if needed.

Manufactured in Spain, by GUIL. The world leading Material Lifting Equipment Suppliers.

The lifter comes with 660 x 60 x 60mm reinforced steel forks and magnetic locking pins as standard for a quick set-up. These forks have a special reversible design to be able to set them at two different heights – gaining more height when full extended. They can also be removed for more convenient transporting and storage.


GUIL Codes:

TORO B-202/C  |  LUM-ELC-017

Features & Benefits

  • Can be operated by one person
  • Compact and lightweight designs for easy handling - corridor and single-door accessible.
  • Fast and easy set-up with no tools required
  • Telescopic removable legs to move the lifter close to a wall if necessary
  • For a quick, easy and safe raising of the lifter it comes with an automatic brake winch which stops and holds the load at the desired height
  • It can be used for industrial and residential installations, for both indoor and outdoor use
  • Folding stabiliser legs, provided with adjustable wheels for levelling
  • Removable, adjustable and reversible load forks
  • Removable legs with telescopic design, provided with adjustable wheels for levelling
  • 12 Heavy duty wheels for vertical and horizontal manoeuvring and its loading onto vehicles
  • It is equipped with two safety systems to guarantee maximum reliability and resistance during the lifting and lowering process
  • The Automatic Braking System stops and holds the load at the desired height: once you have reached the desired height, by letting go of the winch handle the braking system automatically stops and holds the load in place.
  • The Internal Pendulum Brake System consists of an internal pendulum system that is automatically activated on each mast section so that if they were to suddenly fall - this would be easily unblocked by a trigger on each profile.
  • The Mast Section Unblocking System means that each mast has an external trigger allowing the user to unblock the individual profiles when the pendulum brake is activated.
