Buy Electric Straddle Stacker (Mono-Mast) in Pallet Stackers from Astrolift NZ
Model Number

LPS-NBL-002

LPS-NBL-003

Capacity (kg)

1000

1000

Fork Span (mm)

252 - 800

252 - 800

Fork Length (mm)

1150

1150

Lift Height (mm)

40 - 1530

40 - 1930

Free Lift Height (mm)

1530

1930

Lifting Speed (m/s)

0.12 / 0.18

0.12 / 0.18

Lowering Speed (m/s)

0.16 / 0.12

0.16 / 0.12

Mast Height (mm)

1950 - 2570

2350 - 2870

Electromagnetic Brake

Yes

Yes

Travel Speed (km/h)

4

4

Maximum Gradability (%)

10

10

Turning Radius (mm)

1405

1405

Overall Length (mm)

1810

1810

Overall Width (mm)

726

726

Overall Height (mm)

2470

2870

Weight (kg)

637

650



Enquire For Price

+ Quote

Enquire For Price

+ Quote
Specification PDF

Straddle pallet stackers are designed for lifting pallets that have bottom boards. Where a regular stacker's legs go under the pallet, lifting the forks would snap the bottom boards off as they catch on the legs. This straddle stacker has adjustable legs that go around the outside of the pallet to avoid this issue. This machine features both electrically-powered lifting and driving, removing all effort from the operator to move heavy loads. This stacker utilises a single beam mast, providing higher visibility to the operator to see what is in front of the machine. Operators are able to navigate narrow spaces with this machine's compact design and tight turning radius.

  • Battery Type: Built-in Rechargeable
  • Driving: Electric
  • Finish: Powder-coated
  • Leg Position: Straddle
  • Lifting: Electric
  • High contrast display shows battery charge with hours running meter
  • Two 12V 85Ah batteries with built-in charger
  • Monomast design for good visibility of forks and area ahead
  • Adjustable straddle legs suitable for varying pallet sizes
  • Adjustable fork spread suitable for varying pallet sizes
  • Onboard storage areas for documents and tools
  • Variable speed control on the tiller allowing for precise movements
  • Ergonomic driving handle prevents unnecessary strain on users
  • Simple, electric controls to raise and lower the forks
  • Polyurethane (PU) wheels and rollers are durable, non-marking and quiet
  • Robust battery casing keeps battery protected from the environment around it
  • Emergency stop buttons on the tiller and on the main machine
  • Sound level at drivers ear in accordance with EN 12053
  • 1 Year Warranty
